Description
Agricultural Pesticide Sprayer Thermal Fogging Machine
Product name | Fogging Sprayer |
Model | YS-80A |
Tank capacity | Solution an fuel tank is backpack,Mainframe is cross-body |
Solution tank volume | 15L |
Fuel tank volume | 2.0L |
Fuel consumption | 4L/H |
Spray rate capacity | 80L/H |
Spray distance(Water Mist) | 8-14 M |
Spray distance(Smog) | 20-100 M |
Qty.of solution tube | Single |
Qty.of carburetor | Single |
Carburetor material | ADC-12 Aluminum |
Explosion tube material | SUS304 |
Solution tank material | HDPE |
Air pump material | Iron |
Frame Material | Stainless Steel |
Energy Supply | 12V Chargeable battery |
Dimension | 110*24*32 CM |
N.W | 8.5 KG |
Certificate | CE |
Application:
1. Pest control of various fruit trees, agricultural crops and forest park. Like cocoa, rubber, coffee, oil palms, etc.
2. Pest control of greenhouse crops; Increase the temperature in the greenhouse in winter.
3. Sterilization of breeding sites and the farm.
4. The eradication of flies and mosquitoes in various places.
5. Disinfection in public places, such as hospitals, cinemas and schools, etc.
Manual:
1. Pour the solution, then screw the lid very very tight
2. Pour gasoline into the fuel tank (# 92 or more clean gasoline);
3. Squeeze the oil bubbles until they are about four-fifths full;
4. Fully turn on the carburetor switches;
5. Press and hold the green button until the machine is fully started;
6. Turn on the solution and the diesel valves;
7. End of work, first turn off the solution and diesel switch, then turn off the carburetor switch;
