Description
A 1 metre, 38mm diameter three-zone probe for manually collecting samples from stored grain and compatible free-flowing bulk materials. Rotating the inner tube opens and closes the sampling zones along the probe length.
Key features
- Three sampling zones collect material across the inserted depth
- 38mm diameter suits a broad range of grains and granules
- Pointed end supports manual insertion into bulk material
- Stainless construction supports routine cleaning
Technical specification
| Series | QY |
|---|---|
| Supplied length | 1m |
| Nominal diameter | 38mm |
| Sampling configuration | Three-zone rotating inner tube |
| Standard material | 201 stainless steel |
| Number of openings | Three sampling zones |
| Typical media | Grain and compatible free-flowing granules |
| Operation | Manual insertion, rotation and withdrawal |
Listed sales unit
One 1m × 38mm three-zone grain sampling probe.
Application note
Develop a sampling plan appropriate to the commodity and lot size. Clean between lots to prevent cross-contamination, and do not force the probe into compacted material or use near moving machinery.
