1-1/8 in Two-Hole Flange Alignment Pin Set – Black, 2 Piece

Set up and level two-hole pipe flanges faster during fabrication, fit-up and maintenance. This compact two-piece alignment-pin set locates through opposing flange bolt holes to help hold the flange orientation while the joint is prepared for assembly or welding.

Key features

• Two-piece set for simultaneous alignment through two flange holes
• Nominal 1-1/8 in (28.4 mm) body diameter
• Approximate assembled length: 70 mm per pin
• Threaded centre adjustment with knurled gripping surfaces
• Black-finished metal construction
• Compact, reusable tool for workshop and field maintenance

Typical applications

• Pipe fabrication and welding fit-up
• Plant maintenance and shutdown work
• Mechanical assembly, ship repair and heavy-equipment servicing
• Horizontal and vertical flange positioning

Specifications

Compatibility and use

Confirm the flange bolt-hole diameter, flange thickness and required working clearance before purchase. The supplier describes the set for common ASME Class 150 flange fit-up, but compatibility depends on the actual flange dimensions. This is a positioning aid only; it is not a lifting, load-bearing or certified inspection device. Follow site procedures and remove the pins before final bolting or operating the line.

Dimensions are supplier-stated and may vary slightly between production batches. Matrico verifies the ordered model and performs a pre-dispatch visual check. For project quantities or application confirmation, use the single Request a Quote button on this page.
