MG-8 Stainless Steel Bridge Cam Weld Gauge – Metric & Imperial

Inspect common weld dimensions and joint preparation with a compact MG-8 bridge cam gauge. The stainless-steel gauge combines metric and imperial scales for fabrication, workshop and field inspection tasks.

Key features

• Multi-function weld inspection: one pocket-size gauge for several common dimensional checks.
• Metric and imperial scales: read measurements in millimetres or inches from the engraved product scales.
• Stainless-steel construction: suited to regular workshop and site handling.
• Adjustable sliding elements: knurled locks help hold the selected measurement position.
• Compact format: easy to carry for fabrication, maintenance and incoming inspection work.

Typical measurements

• Weld reinforcement / excess weld metal
• Fillet weld leg length
• Fillet weld throat size
• Undercut depth
• Joint misalignment (high-low)
• Angle of preparation from 0–60°
• General linear measurements up to approximately 50 mm

Specifications

Suitable applications

Useful for welders, fabrication supervisors, maintenance teams and inspectors checking shop fabrication, structural work, pipework and repaired components.

Important inspection note

Clean the gauge and weld surface before measurement and confirm zero/reference positions before use. This product is supplied as a general inspection aid. It is not supplied with a traceable calibration certificate. Where a project specification, quality plan or regulated inspection requires calibrated equipment, arrange independent calibration and confirm acceptance requirements before use.

Delivery: Free shipping Australia-wide. Allow approximately 3–8 weeks; remote-area and carrier delays may extend delivery. Contact Matrico before ordering if a fixed project date is required.

Need quantity pricing or inspection advice? Use the Request a Quote button and include the applicable weld standard or project requirements.
